Quick Specs

Figure 1 shows the appearance ofASR1000-ESP100=.

Quick Specs

Table 1 shows the Quick Specs.

Model	NIM-1MFT-T1/E1
Serial data (channel-group*)	2 per port
E1 unframed G.703	Not supported
Voice channel associated signaling (CAS) (ds0-group)	24 per port (T1) 31 per port (E1) 1 per timeslot
PRI (pri-group*)	1 per port
Drop and insert (tdm-group)	24 per port (T1) 31 per port (E1) 1 per timeslot
Dimensions (H x W x D)	1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)

* channel-group refers to bonding of one or more time slots into a single High-Level Data Link Control (HDLC)-framed serial connection for IP data traffic connectivity. This connection is used for HDLC, Frame Relay, and Multilink PPP (MLPPP) serial WAN connections. ds0-group refers to bonding of one or more time slots into a single TDM voice connection using CAS such as ear and mouth (E&M), foreign exchange station (FXS), or foreign exchange office (FXO). This connection is used for TDM PBX or PSTN connections and typically is deployed only on T1. * pri-group refers to bonding of two or more time slots into a single TDM connection using ISDN signaling. This connection is typically used for TDM PBX or PSTN voice connections on T1 and E1, and also for data WAN connections on E1. Each call on the PRI is individually indicated as being a voice or data call with the ISDN bearer capability delivered with the call. Signaling is done on the D-channel, which is always channel 24 on a T1 and channel 31 on an E1. tdm-group refers to cross-connecting one or more time slots from one TDM interface to another. This connection is used to groom channels from different access points onto a combined T1 or E1 uplink. Because the router merely cross-connects and does not interpret or route the traffic from the ingress interface to the egress interface, the traffic type (voice and data) is transparent to the router.

Quick Specs

Figure 1 shows the appearance ofSPA-8X1GE-V2=. Table 1 shows the Quick Specs.

Product Code	SPA-8X1GE-V2=
Product compatibility	*Cisco 12000 Series Router (2-, 5-, 8-, and 10-port GE SPAs) *Cisco XR 12000 Series Router (2-, 5-, 8-, and 10-port GE SPAs) *Cisco ASR 1000 Series Router (2-, 5-, 8-, and 10-port GE SPAs) *Cisco CRS Carrier Routing System (5-, 8-, and 10-port GE SPAs)
Port density per SPA	2*, 5, 8, or 10 Gigabit Ethernet ports * Usable in combination of SFP and RJ-45 ports for a total of 2 Gigabit Ethernet ports
Physical interfaces	*Short wavelength (SX) *Long reach/long haul (LX/LH) *Extended distance (ZX) SFP *SFP-GE-T (5-, 8-, and 10-port Gigabit Ethernet SPAs) *Built-in RJ-45 (2-port Gigabit Ethernet SPA)
Reliability and availability	*OIR of the SPA within the SIP and the optics within the SPA *Field-replaceable SFP optical modules
Physical specifications	8-port Gigabit Ethernet SPAs: ● Weight: 0.75 lb (0.34 kg) ● Height: 0.8 in. (2.03 cm) (single height) ● Width: 6.75 in. (17.15 cm) ● Depth: 7.28 in. (18.49 cm)
Power	● 8-port Gigabit Ethernet SPA: 20W (with SX and LX optics); 22.3W (with ZX optics)
