C9300-NM-8X

Quick Spec

Parameter	Data
Product Name	NIM-4BRI-NT/TE
Ports	4-port BRI
Interface Type	Network Interface Module (NIM)
Compatibility	Cisco ISR 4000 Series
Network Protocol Support	ISDN

Product Features

• Four BRI ports for flexible connectivity.
• Supports both NT and TE modes for ISDN line.
• Integrated with Cisco's ISR 4000 series for streamlined infrastructure.
• High performance for voice and data integration.
• Easy to install and manage.

Product Applications

1. Small and medium-sized businesses looking for cost-effective voice solutions. 2. Enterprises aiming to integrate voice and data traffic. 3. Organizations requiring high-density voice connectivity for their ISR routers.

Supported Options

Accessory	Model
High-speed WAN Interface Cards	HWIC-4B-S/T
PVDM Modules	PVDM4-32
Power Supply	PWR-4450-AC

Compare to Similar Items

Model	Differences
NIM-4BRI-NT/TE	N/A - Current Product
NIM-2BRI-NT/TE	2-port BRI vs. 4-port BRI
NIM-4MFT-T1/E1	Digital voice/data module vs. BRI voice module

Quick Specs

Figure 1 shows the appearance ofSPA-1XOC12-POS-V2=. Table 1 shows the Quick Specs.

Product Code	SPA-1XOC12-POS-V2=
SPA	1-Port OC-12c/STM-4 POS SPA
SIP Supported:Cisco ASR1000-SIP10	Yes
SIP Supported:Cisco ASR1000-SIP40	Yes
Number of Ports	2 (ships SPA-2XOC12-POS)
Minimum IOS XE Release	Cisco IOS XE 2.4
Minimum Hardware Revision	1.0

The Configuration

Table 2 shows the recommended elements for the SPA-1XOC12-POS-V2=.

Model	Description
SFP-OC3-LR2	OC3/STM1 SFP, Single-mode fiber, Long Reach (80km)
SFP-OC3-LR1	OC3/STM1 SFP, Single-mode fiber, Long Reach (40km)
SFP-OC12-SR	OC12/STM4 SFP, Short Reach
SFP-OC3-IR1	OC3/STM1 SFP, Single-mode fiber, Intermediate Reach
SFP-OC3-SR	OC3/STM1 SFP, Single-mode fiber, Short Reach
SFP-OC12-IR1	OC-12/ STM-4 SFP, Intermediate Reach (15km)

Quick Specs

Figure 1 shows the appearance ofSPA-8X1GE-V2=. Table 1 shows the Quick Specs.

Product Code	SPA-8X1GE-V2=
Product compatibility	*Cisco 12000 Series Router (2-, 5-, 8-, and 10-port GE SPAs) *Cisco XR 12000 Series Router (2-, 5-, 8-, and 10-port GE SPAs) *Cisco ASR 1000 Series Router (2-, 5-, 8-, and 10-port GE SPAs) *Cisco CRS Carrier Routing System (5-, 8-, and 10-port GE SPAs)
Port density per SPA	2*, 5, 8, or 10 Gigabit Ethernet ports * Usable in combination of SFP and RJ-45 ports for a total of 2 Gigabit Ethernet ports
Physical interfaces	*Short wavelength (SX) *Long reach/long haul (LX/LH) *Extended distance (ZX) SFP *SFP-GE-T (5-, 8-, and 10-port Gigabit Ethernet SPAs) *Built-in RJ-45 (2-port Gigabit Ethernet SPA)
Reliability and availability	*OIR of the SPA within the SIP and the optics within the SPA *Field-replaceable SFP optical modules
Physical specifications	8-port Gigabit Ethernet SPAs: ● Weight: 0.75 lb (0.34 kg) ● Height: 0.8 in. (2.03 cm) (single height) ● Width: 6.75 in. (17.15 cm) ● Depth: 7.28 in. (18.49 cm)
Power	● 8-port Gigabit Ethernet SPA: 20W (with SX and LX optics); 22.3W (with ZX optics)

Quick Specs

Figure 1 shows the appearance of PVDM4-128. Table 1 shows the Quick Specs.

Product Code	PVDM4-128
Slot	On-board motherboard or T1/E1 module slot
Description	128-channel high-density voice DSP module
Low Complexity	128
Medium Complexity	96
High Complexity	64

Compare to Similar Items

Table 2 shows the comparison of PVDM4-64, PVDM4-32 and PVDM4-128.

Product Code	PVDM4-64	PVDM4-32	PVDM4-128
Slot	On-board motherboard or T1/E1 module slot	On-board motherboard or T1/E1 module slot	On-board motherboard or T1/E1 module slot
Description	64-channel high-density voice DSP module	32-channel high-density voice DSP module	128-channel high-density voice DSP module
Low Complexity	64	32	128
Medium Complexity	48	24	96
High Complexity	32	16	64
