NIM-2CE1T1-PRI

Model: Cisco Multiflex Trunk Voice and WAN network interface module NIM-2CE1T1-PRI
In Stock

Quick Spec

The figure shows the appearance of NIM-2CE1T1-PRI.

Table 1 shows the quick spec.

Product Number NIM-2CE1T1-PRI
Product Description 2 port Multi-flex Trunk Voice/Channelized Data T1/E1 Module
Number of Ports 2
Dimensions (H x W x D) 1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)
Weight 0.42 lb (191g)

Supported Devices

Table 2 shows the supported devices for the NIM-2CE1T1-PRI.

Product number Model Description
Cisco ISR4321/K9 Cisco ISR 4321 (2GE,2NIM,4G FLASH,4G DRAM,IP Base) 50Mbps-100Mbps system throughtput, 2 WAN/LAN ports, 1 SFP port, multi-Core CPU,2 NIM, Security, Voice, WAAS, Intelligent WAN, OnePK, AVC
Cisco ISR4331/K9 Cisco ISR 4331 (2GE,2NIM,1SM,4G FLASH,4G DRAM,IP Base) 100Mbps-300Mbps system throughtput, 2 WAN/LAN ports, 2 SFP ports, multi-Core CPU,1 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
Cisco ISR4351/K9 Cisco ISR 4351 (3GE,3NIM,2SM,4G FLASH,4G DRAM,IP Base) 200Mbps-400Mbps system throughtput, 2 WAN/LAN ports, 3 SFP ports, multi-Core CPU,2 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
Cisco ISR4431/K9 Cisco ISR 4431 (4GE,3NIM,8G FLASH,4G DRAM,IP Base) 500Mbps-1Gbps system throughtput, 4 WAN/LAN ports, 4 SFP ports, multi-Core CPU, Dual-power, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC, separate control data and services CPUs

Compare to Similar Items

Table 3 shows the comparison between NIM-2CE1T1-PRI and NIM-8MFT-T1/E1.

Product Number NIM-2CE1T1-PRI NIM-8MFT-T1/E1
Product Description 2 port Multi-flex Trunk Voice/Channelized Data T1/E1 Module 8 port Multi-flex Trunk Voice/Clear-channel Data T1/E1 Module
Number of Ports 2 8
Dimensions (H x W x D) 1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm) 1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)
Weight 0.42 lb (191g) 0.52 lb (236g)

Description

NIM-2CE1T1-PRI Overview

The Cisco® Fourth-Generation 2-Port T1/E1 Multiflex Trunk Voice and WAN Network Interface Modules (NIMs) NIM-2CE1T1-PRI supportS data and voice applications on the Cisco 4000 Integrated Services Routers. These cards combine WAN-interface-card (WIC), voice-interface-card (VIC), ISDN Primary Rate Interface (PRI), dial-access integration, and channelized-data (CE1T1) functions to provide superior flexibility, versatility, and investment protection through their many uses. Customers who choose to integrate data and voice in multiple steps preserve their investment in a T1/E1 WAN interface.

NIM-2CE1T1-PRI Specification

NIM-2CE1T1-PRI Specification

Product Number NIM-2CE1T1-PRI
Product Description 2 port Multi-flex Trunk Voice/Channelized Data T1/E1 Module
Number of Ports 2
Clear-Channel Data Yes
MFT Packet Voice Yes
Unstructured E1 (G.703) Support Yes
Channelized Data Yes
Dimensions (H x W x D) 1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)
Weight 0.42 lb (191g)
Environmental ●  Operating temperature: 0 to 50°C (32 to 122°F)

●  Storage temperature: -20 to +65°C (-4 to 148°F)

●  Relative humidity: 10 to 85% noncondensing operating; 5 to 95% noncondensing, nonoperating

T1 Compliance (partial list) ●  TIA-968-A

●  CS-03

●  Jate

●  ANSI T1.403

E1 Compliance (partial list) ●  TBR4, TBR12, and TBR13

●  ITU-T G.703, G.704, G.823, and I.431

●  S016 (Australia)
