SFP-10G-ER-S=
Model:
SFP-10G-ER-S= - Cisco SFP GLC Module
In Stock
Categories: Cisco, Cisco Modules & Cards
Quick Spec
Table 1 shows the quick spec.
Product Model | SFP-10G-ER-S= |
Data Rate | 10 Gbps |
Wavelength | 1550 nm |
Maximum Distance | 40 km |
Connector Type | LC |
Fiber Type | Single-mode |
Description
SFP-10G-ER-S= Overview
10GBASE-ER SFP Module, Enterprise-Class
The SFP-10G-ER-S= is a single-mode fiber transceiver designed for use with compatible Huawei switches and routers. It supports 10 Gigabit Ethernet connectivity over distances of up to 40 kilometers, making it ideal for use in long-range network applications.
SFP-10G-ER-S= Specification
SFP-10G-ER-S= Specification | |
Product Model | SFP-10G-ER-S= |
Data Rate | 10 Gbps |
Wavelength | 1550 nm |
Maximum Distance | 40 km |
Connector Type | LC |
Fiber Type | Single-mode |
Be the first to review “SFP-10G-ER-S=” Cancel reply
