VWIC3-1MFT-G703

Model: VWIC3-1MFT-G703 Cisco Voice/WAN Card
In Stock
Login To See Price
Categories: ,

Quick Spec

Brand Cisco
Model VWIC3-1MFT-G703
Interface Type T1/E1
Compatibility Cisco ISR G2 Routers
Form Factor Plug-in module

Product Features

  • ● ● Supports both data and voice applications
  • ● ● Integrated T1/E1 and G.703 connectivity
  • ● ● High-density design for efficient use of router slots
  • ● ● Flexible configuration options
  • ● ● Enhanced voice quality and data transmission rates

Product Applications

  • ● ● Voice over IP (VoIP) deployment in medium to large enterprises
  • ● ● High-speed data transmission for remote office connectivity
  • ● ● Enhanced WAN connectivity for branch offices

Supported Options

Accessory Model
Cable CAB-E1-RJ45BNC
Transceiver Module GLC-T
Interface Card EHWIC-1GE-SFP-CU

Compare to Similar Items

Model Difference
VWIC3-2MFT-T1/E1 Supports dual T1/E1 ports
VWIC2-1MFT-G703 Previous generation with lower performance
HWIC-1DSU-T1 T1 support only, does not support E1 or voice functionalities

Description

VWIC3-1MFT-G703 Overview

The Cisco VWIC3-1MFT-G703 is an advanced Voice and WAN T1/E1 interface module, designed to deliver enhanced connectivity and performance. This versatile module supports multiple configurations, making it suitable for various networking environments. With robust features and reliable performance, the VWIC3-1MFT-G703 is an ideal choice for efficient data and voice communication solutions.

VWIC3-1MFT-G703 Specification

VWIC3-1MFT-G703 Specifications
Brand Cisco
Model VWIC3-1MFT-G703
Type Voice and WAN Interface Card
Interfaces T1/E1
Port Count 1
Protocols G.703
Form Factor Plug-in module
Data Rate 1.544 Mbps (T1), 2.048 Mbps (E1)
Compatibility Compatible with Cisco 2900 and 3900 series routers
Features Supports voice, video, and data applications
Coding AMI, B8ZS, HDB3
Transmit Signal RJ48C
Impedance 120 ohm (balanced), 75 ohm (unbalanced)
Mounting Type Internal
Power Consumption Varies with configuration
Operating Temperature 0��C to 40��C (32��F to 104��F)
Storage Temperature -40��C to 70��C (-40��F to 158��F)
Humidity 5% to 95% non-condensing
Dimensions 7.11 cm x 16.51 cm x 1.22 cm
Approvals FCC, UL
Warranty 1 year limited warranty
